HINGES AND HARDWARE FOR GLASS ENCLOSURES: SHOWERS, DOORS …

Index
646-740
1. Hinges for shower doors and gates

646
2. The precision butt hinge: Capsi or Reversi
3. Capsi self-closing hinges, Isodouche type
4. Capsi self-closing hinges, for glass thickness 8
5. Reversi self-closing hinges, for glass thickness 8
6. Reversi self-closing hinges, Saloon type

647
7. Minidouche and Super Venus, Year 2000 hinges
8. Minidouche self -closing hinge
9. Super Venus indexing hinge

648
10. Isodouche, Saloon, Super Venus, Venus: classic
11. Venus indexing hinges
12. Super Saloon self-closing hinges
13. Saloon self-closing hinges
14. Isodouche self-closing hinges

649
15. Adler Selection self-closing hinges: try them!
16. R. Fattorini self-closing hinges
17. Adler Selection self-closing butt hinges
18. Adler Selection Saloon self-closing tube hinges
19. Adler Selection single-action cushioned self-closing hinges
20. Adler Selection double-action cushioned self-closing hinges
21. Adler Selection Queen stainless steel hinges

732
22. Adlock in stainless steel; Adler VF in aluminium
23. Adlock offset pin tube hinges
24. Tube hinges and clips for laminated glass 55.2
25. Adlock spot fixing connectors

740
26. Clip-In Door butt and tube hinges

503-505
27. SCREEN AND DIVIDER CLIPS

503
28. Capsi, Adslide, Adler clips: showers, guards
29. Capsi clips: Capsi hinges but fixed!
30. Adslide: miniaturized claws for 8 mm thickness

31. Capsi clips: range of square clips 40 x 40
32. Capsi clips: design clips in stainless steel
66. Adslide Alu : clips for threhold sections

504
33. Adler and Venus clips: shower and handrail
34. Venus clips: clean design, always original

505
35. Adler Selection clips : shower and guard

36. Adler S clips for showers, partitions, counters

698
37. Door knobs, Stiffeners
38. Adler and Capsi knobs for doors and gates
39. Capsi square knob 30

40. Adler knob dia.26
41. Adler knob dia.20
42.
Adler knob dia.35

699
43. Clip-on or screw-fixed stiffener, for enclosures, partitions

44. Adslide stiffener dia.25
45. Capsi stiffener, 20 square

46. Adler adjustable clip-on stiffener

705-780
47. Door handles and locks


705
48. Adler Selection stainless steel handles, various types
49. Square stainless steel handle


707
50. Adlock stainless steel lever handles with or without lock
51. Adlock round stainless steel handle


780
52. Aluminium sections: wall, threshold, edge, seal

53. Aluminium sections for shower enclosures
54.
Aluminium make-up section for door panels

55. Aluminium edge section: protection and seal
56. Miscellaneous flat aluminium sections

67. Aluminium rebate sections for glass thickness 8 mm

790-805
57. SEALS AND WATERPROOFING PROFILES

790
58. Seals and waterproofing profiles

59. The waterproofing profiles for the Epsila range
60.
Range of PVC clip-on seals and waterproofing profiles

61. Standard profile for an aluminium edge groove

805
62. Adler Kit seals and waterproofing profiles

63. The range of Adler seals in Adler Kit
64. Adler Kit: seal for aluminium edge

65. Adler Kit: mitring cutter for seals



1. Hinges for shower doors and gates
2. The precision hinge: Capsi ou Reversi

3. Capsi self-closing hinge, Isodouche type
A complete range of self-closing hinges uniquely advantageous to use: a patented mechanism guaranteeing self-closing precision to the millimetre at the door end enabling watertight shower cubicles to be installed without seals; endurance tested to 200,000 cycles; extreme miniaturisation (57x57 mm, 2/3 the size of a visiting card!), even for heavy doors of 50 to 100 kg depending on the model; great versatility, supporting glass of 6 to 12 mm, or wood up to 21 mm,...; a self-closing position continuously adjustable over +/- 90°; efficient self-closing over a minimum of +/-30° (up to +/- 45° depending on the dimensions of the door) in the Isodouche version; a fully watertight mechanism. Hinges designed and patented by ADLER SAS, 100% manufactured in France in aluminium bronze, a traditional alloy for ironmongery 2½ times stronger than brass or stainless steel. Capsi registered pattern model, with external screws and customizable cover plates: particularly robust for heavy use or risk of being forced beyond +/-90°; or Reversi model with visible screws on the inside: a minimalist, very clean, square product line. Various finishes.
Adler cover plate
x5
chromed 64620Q
brushed chromed 64621R
gilded 64622S
Neutral cover plate
x5
chromed 64630A
brushed chromed 64631B
gilded 64632C
Cover plate for hinge wall/gl
x4 Set of 2
chromed 64610D
brushed nickel 64611F
gilded 64612G
Self-closing hinge Isodouche wall/gl x2

chromed
64600T
brushed nickel 64601U
gilded 64602V
Self-closing hinge    wall/gl x2

chromed
64615K
brushed nickel 64616L
gilded 64617M
Self-closing hinge    prestige wall/gl x2

chromed
64644R
brushed nickel 64645S
gilded 64646T
Self-closing hinge    prestige wall/gl x2

chromed
64647U
brushed nickel 64648V
gilded 64649W
Self-closing hinge    prestige gl/gl 90° x2
chromed
64640M
brushed nickel 64641N
gilded 64642P
Self-closing hinge    prestige gl/gl 180° x2
chromed
64670U
4. Capsi self-closing hinges for glass thickness 8
The existing range of Capsi and Reversi hinges designed for the construction of shower cubicle faces in 8 mm coated glass: assembly with adequate stiffness; possible use of special types of glass, for example lifetime antiscale treated; optimised cost. The hinges in this special range represent an optimum blend of the characteristics of the existing hinges and are suitable for shower cubicle doors not generally weighing more than 35 kg. Steel plunger and cam for sharper self-closing; stainless steel bearing washers suitable for doors weighing well below 50 kg; metal shims suitable for 8 mm glass. 2 models: Capsi and Reversi. 3 finishes as standard: chromed, brushed stainless steel finish, gilded. 2 possible mountings: on wall shim section 25x25-33 mm, to compensate for inability to take the dimensions to the millimetre (before tiling for example); or at the back of a Capsi clip to form a 180° glass/glass hinge; or on wall, on flat wall section or combined with a counterplate to form a 90° glass/glass hinge. Efficiency that makes real luxury accessible in the shower.
Shim kit for hinge
th.6-10
x3 set J4
natural cork 64666Q
Shim kit for hinge
th 8-12
x3 set J4
transparent plastic 64667R

Shim kit for hinge
th.10
J4
aluminum 64679D

Self-closing hinge    wall th.8 – all metal x2

chromed
64672W
brushed nickel 64673X
gilded 64674Y
Self-closing hinge    section th.8 – all metal x2

chromed
64675Z
brushed nickel 64676A
gilded 64677B
Adapter kit hinge gl/gl 90° x2

chromed
64689Q
brushed nickel 64690R
gilded 64691S
5.Reversi self-closing hinges for glss thickness 8
Adapter kit hinge gl/gl 90° x2

chromed
64686M
brushed nickel 64687N
gilded 64688P
Self-closing hinge    wall th.8 - all metal x2

chromed
64692T
brushed nickel 64693U
gilded 64694V
Self-closing hinge    section th.8 - all metal x2

chromed
64695W
brushed nickel 64696X
gilded 64697Y
6. Reversi self-closing hinges Saloon type
The advantages of the Isodouche Capsi hinge available in the Saloon application: the hinge returns over an opening of +/-90° around the self-closing position, within a limit of +/- 90° around the hinge pin. Such an extensive return over a wider range is naturally weaker: so it should be reserved for lightweight gates and doors typically weighing less than 35 kg. For glass 6 to 10 mm in thickness.
Self-closing hinge saloon wall/gl x2

chromed
64656D
brushed nickel 64657F
7. Minidouche and Super Venus Year 2000 hinges
8. Minidouche self-closing hinge
If the classic is a must, MINIDOUCHE is made for you! A self-closing hinge with a proven mechanism (the Isodouche® one), small in size (82 mm x 54.5) but robust in construction, it is intended for doors of 8 and 10 mm thickness (up to 31 kg). For larger size, increase the number of hinges per door (typically 3 hinges per door), consulting the professional rules, or choose different Adler models (Isodouche, Super Venus, Super Saloon, Capsi). It stops in any position except the 15° zone on either side of the 90° position: Isodouche self-closing. Very strong die cast brass. The self-closing motor is integral with the plate casting: the visible connecting screws in the Isodouche have disappeared; the construction is far more robust. Supplied with cut shims.
Self-closing hinge    wall/gl x2

chromed
64753K
Self-closing hinge    wall/gl - 1/2 plate x2

gilded
64764W
Self-closing hinge    gl/gl 90° x2
chromed
64758Q
brushed nickel 64760S
Self-closing hinge    gl/gl 180° x2

gilded 64756N



9. Super Venus indexing hinges
The Super Venus hinges form the synthesis between a high end design product line (registered pattern), an innovative mechanism (ADLER SAS patent for the spring ring self-closing mechanism, without doubt the simplest on the market) and remarkable mechanical properties: design load 50 kg (2 m (H) x 1 m (l) in 10mm glass), corrosion and dirt free. They are intended for 8 and 10mm glass. The Super Venus hinges hold the door securely and provide self-closing in zones close to 0°, 90° and 180°. For self-closing in an exact position, we recommend also fitting magnetic waterproofing seals (see 790). Very strong die cast brass.
Self-closing hinge    wall/gl x2

chromed
64700B
matt chromed 64711P
white 64703F
gilded 64702D
Self-closing hinge    gl/gl 180° x2
chromed
64704G
matt chromed 64710N
white 64707K
gilded 64706J
nacré 64705H
Self-closing hinge    wall/gl 45° x2

chromed
64708L

10. Isodouche, Saloon, Super Venus, Venus: classic
11. Venus indexing hinges
Smaller size, high end design (registered pattern) corrosion and dirt resistance (ADLER SAS patent) make the VENUS hinges the ideal accessory for fitting to shower gates up to 25 kg, in glass of 6 mm (Venus 6) or 8 mm (Venus) (1.85 m (H) x 0.90 (l) in 6 mm glass). The VENUS hinges hold the door securely and provide self-closing in zones close to 0°, 90° and 180°. For self-closing in an exact position, we recommend also fitting magnetic waterproofing profiles (see 790) or forcing a halt at the door stop on a shower cubicle upright. Very strong die cast brass. The “pearlised” finish corresponds to "matt chromed". The "gilded" is electroplated.
Self-closing hinge    th.6 - wall/gl x2

chromed
64860A
matt chromed 64862C
white 64863D
gilded 64854U
Self-closing hinge    th.8 - wall/gl x2

chromed
64880X
matt chromed 64882Z
white 64883A
gilded 64856W
pearlised 64881Y
Self-closing hinge    th.6 - gl/gl 90° x2

chromed
64870M
matt chromed 64872P
white 64873Q
gilded 64859Z
pearlised 64871N
Self-closing hinge    th.8 - gl/gl 90° x2

chromed
64890J
matt chromed 64893M
gilded 64864F
pearlised 64891K


Self-closing hinge    th.8 - gl/gl 135° x2
chromed
64801M
matt chromed 64823L
white 64879W
gilded 64820H
Self-closing hinge    th.6 - gl/gl 180° x2
chromed
64865G
matt chromed 64868K
white 64857X
gilded 64866H

Self-closing hinge    th.8 - gl/gl 180° x2
chromed
64885C
matt chromed 64887F
white 64888G
gilded 64858Y
pearlised 64886D
Self-closing hinge    th.6 - gl/gl 180° x2
chromed
64875S
matt chromed 64877U
white 64878V
gilded 64869L
pearlised 64876T
Offset indexing hinge th.8 - gl/gl 180° x2
white
64898S
gilded 64897R
pearlised 64896Q

12. Super Saloon self-closing hinges
Super Saloon hinges, stop at +/-90° over a 10° range and very precise self-closing due to a high cut-off at 0° from any other position; for quite large doors, typically up to a height of 2m10, and a width of 1m00, in 10mm thickness. Maximum load 52kg for one pair of hinges. An efficient solution for side hung doors in passages: possible if they are fixed to a perfectly square architrave or frame. Supplied with stainless steel wood screws 5 x 40 mm and cut shims.
Self-closing hinge    th.10 - wall/gl x2

chromed
64831U
natural brushed aluminium 64827Q
white epoxy 64828R
gilded 64829S
natural polished aluminium 64830T
13. Saloon self-closing hinges
SALOON A® hinges: stop at 0° and 180° (in a zone of 10°) and self-closing on 90° in any other position; SALOON SA®: self-closing in any position on 90°; for door thickness of 8 to 10 mm. Maximum load: for one pair of hinges, standard model = 31 kg – H x l = 180 x 70 cm; or “45” model: 45 kg – H x l = 190 x 95 cm. Brass. Supplied with wood screws 5 x 40 mm and cut shims.
Self-closing hinge stop - wall/gl x2

chromed
64822K
matt chromed 64824M
gilded 64825N

Self-closing hinge stop 45kg - wall/gl x2

chromed
64810W
matt chromed 64811X
gilded 64833W

Self-closing hinge no stop - wall/gl x2

chromed
64812Y
matt chromed 64814A
gilded 64832V

Self-closing hinge no stop 45kg - wall/gl x2

chromed
64815B
matt chromed 64817D
gilded 64847M

14. Isodouche self-closing hinges
ISODOUCHE hinges: stop in any position except in the 15° zone on either side of the 90° position; for door thickness of 8 to 10 mm, maximum load for one pair of hinges, standard model: 31 kg (H x l: 180 x 70 cm); or “45” model: 45 kg (H x l: 190 x 95 cm). Brass. Supplied with cut shims.
Self-closing hinge wall/gl x2

chromed
64802N
matt chromed 64804Q
brushed chromed 64803P
gilded 64800L
white 64845K
Self-closing hinge 45kg - wall/gl x2

chromed
64805R
matt chromed 64807T
brushed chromed 64809V
gilded 64819G

Shim plate th.3 PC

chromed
64834X
gilded 64835Y

Self-closing hinge gl/gl. 90° x2

chromed
64839C
matt chromed 64840D
gilded 64853T

Self-closing hinge gl/gl.180° x2

chromed
64836Z
matt chromed 64837A
gilded 64848N
white 64846L

15. Adler Selection self-closing hinges: try them!
16. R. Fattorini self-closing hinges
An extensive range of hinges of European manufacture meeting the standards for glazed installations: a design which is now a market classic; the advantage of an adjustable self-closing position (Adler-Capsi principle); impeccably finished in the 2 standard finishes, chromed and brushed nickel (similar to brushed stainless steel). These hinges have a capacity of 40 kg/pair, suitable for the majority of shower enclosure doors. All the other models in the Renato FATTORINI range are available on request: no self-closing angle adjustment, with half-moon offset pin... Consult ADLER SAS. For glass of 8mm thickness.
Self-closing hinge - adjustable wall/gl x2

chromed
64950Y
brushed chromed 64951Z

17. Adler Selection self-closing butt hinges
Self-closing hinge wall/gl x2
chromed
64952A

Self-closing hinge gl/gl.90° x2
chromed
64953B
Opening 11 to 14 mm / glass th. – shim
Note: the door notch depth depends on the thickness of the fixed glass and the play between the door and the fixed glass counterplate: as with the hinge, the fixed glass counterplate is on the inside of the hinge at 90°.
Self-closing hinge gl/gl.180° x2
chromed
64954C

18. Adler Selection Saloon self-closing hinges
Self-closing hinges with central pin (even hinges at top and bottom of door) for doors to chilled cabinets, display cabinets etc. They self-close at an angle de +/-30°. They are very practical for installation of insulated cabinet doors in a chilled cabinet section of a store, ensuring that they close fully after being opened by customers, keeping them closed the rest of the time, making these sections more convenient and providing substantial energy savings. Maximum capacity of 50 Kg/pair. For glass of 8 to 10 mm thickness.
Pivot hinge x2
chromed
64905Z

19. Adler Selection single-action cushioned self-closing hinges
The TRIPLE ACTION closers comprise hinges and latches for glass doors and gates of innovative, patented design. They prevent any risk of malfunction (noise, vibration, premature aging) without adjustment. The latches designed for swimming pool glass safety barriers are magnetic: the bolt emerges opposite the strike plate and cannot impede the gate when it closes. The hinges have a dual self-closing system: mechanical by magnetic torsion spring for maximum holding torque at the end of return; and a system of stainless steel dampers to brake the door hydraulically at the end of closing, preventing the fingers being trapped and destructive shock and vibration to the hinge and latch fixings. In any situation, the automatic closing is faultless and cushioned for any door opening from 0° to 90°. The hinge is still very compact: its clean forms match the varied designs of the other door components: ADLOCK handles and locks etc. These hinges are suitable for fitting to store fronts, interior doors, entrances, offices etc., replacing floor pivots and tube hinges. For coated glass 10 to 12 mm thickness.
Self-closing hinge gl/gl.180° - single exterior action unit
PSS 64920R

Self-closing hinge wall/gl - single exterior action                  unit

PSS
64922T
BSS 64923U

Self-closing hinge wall/gl - single interior action   unit

PSS 64925W

Plate wall/gl - 4 screws unit
  PSS 64926X
BSS 64927Y

Plate tube/gl - dia.50 unit
PSS 64928Z
BSS 64929A


20. Adler Selection double-action cushioned self-closing hinges
Double-action stainless steel hinges with cushioned self-closing: they are an effective replacement for door closers and floor or lintel pivots. Sold in pairs: the top hinge is the self-closer and the bottom one limits and controls the closing speed. Regulation of the speed is very easy and reliable. For wall-glass installation, the door can weigh up to 65 kg and measure up to 2m40; for 180 degree glass-glass installation, the door weight is limited to 45 kg. The hinge operation is double action: opening with automatic return over +/- 85° around the closed position; holding in open position of 85 to 90°. These hinges are made of stainless steel and are very resistant to corrosive environments: outdoor, swimming pool etc., and have the advantage of a durable self-closing mechanism.
Self-closing hinge wall/gl Set of 2

BSS
64955D

Self-closing hinge gl/gl.180° Set of 2

BSS
64956F

21. Adler Selection Queen stainless steel hinges
Polished stainless steel hinges of German manufacture, finished to an impeccable quality standard, with the option during installation of adjusting the stop angle and holding in position on the stop. Shown here in 180° glass/glass versions. Design load = 45 kg. Glass thickness = 8 or 10 mm.
Lift-off hinge gl/gl.180° unit
PSS
64900U

Lift-off hinge gl/gl.180° offset unit
PSS
64901V

Drilling kit unit

22. Adlock in stainless steel; Adler VF in aluminium
23. Adlock offset pin tube hinges
This stainless steel tube hinge range designed by Adler is the perfect complement to the Adlock handles (see 707) for fitting to doors made from 6 to 15 mm glass. Innovative, very efficient and invisible locking system. Easily adaptable to a different door thickness (on request). Standard finish brushed stainless steel.
Washer dia.60
untempered laminated glass
for single spacer
Set of 2
BSS

Rectangular free pivot insert unit

plain
73114X

Socket, top/bottom/
free pivot, wide plate
unit
BSS
73234C

Added fixing point
for tube Ø25
unit

BSS
73233B
Option point supplémentaire
insert
PC
BSS
73267P
Tube hinge, top/bottom/free pivot 8-16mm Set of 2

PSS
73275X
BSS 73221P
Tube hinge, full height
free pivot – height < 3m
unit
BSS 73226U

Tube hinge, full height
adjustable rectangular insert
unit

BSS
73265M
Height > 3m
unit
optional extra
Mirror polished finish option
unit
optional extra
24. Tube hinges and clips for laminated glass 55.2
With Adlock, Adler has developed an innovative patented solution which even enable uncoated laminated glass panels to be spot fixed and surface mounted on a stainless steel tube (tube hinge or connector) to form a totally reliable, purely mechanical system. With the tube hinges and clips for laminated glass 55.2, this principle is designed for clipping onto the edge of glass panels: This tightening method is very efficient and can be used directly metal on glass for a supremely elegant design and greater ease of installation. For thinner lamination (44.2), it is possible to install the system using sheets of cork laid in the gap of the clip at full height, the overhang being trimmed with the cutter flush with the clip after tightening. Naturally, these clips, lift-off hinges and tube hinges are suitable for coated glass panels (55.2 or 10 mm monolithic). The double-action lift-off and tube hinges are anti-finger-trap. It is possible to make up as much as 15 mm in the width of a door by controlling the area of glass in the clip. Butt and tube hinges are adjustable to the height of the door.
Adjustable hinge full height
55.2 - 10mm tempered
unit 2m75
chromed
73282F
BSS anodised 73285J
plain 73270S

Tube hinge rectangular pin
55.2 10 mm tempered
unit 2m75

chromed
73280C
BSS anodised 73283G
plain

73249U

Adjustable hinge
55.2 10 mm tempered
unit
chromed
73281D
BSS anodised 73284H
plain 73271T
26. Adlock spot fixing connectors
Hinge full height
unit 2m60
chromed
74011X
BSS anodised 74001M
natural anodized 74000L

Bottom section / partition section
unit

BSS anodised
74009V



Plate / wall
unit
chromed
74013Z
BSS anodised 74005R
natural anodized 74004Q

Top / bottom pivot plate
unit

BSS anodised
74008U



Plate / wall
unit
chromed
74012Y
BSS anodised 74003P
natural anodized 74002N

27. Screen and divider clips
28. Capsi, Adslide, Adler clips: showers, guards
29. Capsi clips: Capsi hinges but fixed!
The large model Capsi clips reproduce the design of the Reversi hinges (smooth outer face, visible screws on the inside) and their dimensions. Used for wall fixing of the fixed shower cubicle panels and also as a clip for a 180° glass-glass hinge, they provide perfect homogeneity of construction for a shower enclosure to give an extremely clean and minimalist overall design. With the same concept as the plates and counterplate of a Capsi hinge and also in aluminium bronze, they offer the same tightening efficiency for panels up to 100 kg. The notches in the glass panels are the same as in the Capsi hinges, which simplifies the overall concept and makes some panels symmetrical if required (an advantage in the case of single face anti-scale treatments etc.). They are available as standard versions in chromed, brushed nickel (brushed stainless steel finish) and gilded. For 8 mm glass as standard. For a different thickness (from 6 to 12 mm), add sets of shims 64666Q, 64667R or 64679D.
Counterplate clip 57x57 to be screwed M5 - th.8 x2

chromed
50330H
brushed nickel 50331J
gilded 50332K

Counterplate clip 57x57 to be fixed dia. 5.2 x2

chromed
50333L
brushed nickel 50334M
gilded 50335N

Adaptation kit clip gl/gl 90° x2

chromed
64686M
brushed nickel 64687N
gilded 64688P
30. Adslide: miniaturized claws for 8 mm thickness
In many situations of installation of shower panels or office partitions, the only function of the clips is to prevent the glass moving perpendicular to its plane. They do not then need to be clips: a “claw” which simply blocks these free movements of the glass is enough. Adler has pushed its pursuit of miniaturisation to the limit and offers the Adslide clip: it is aluminium, chromed or brushed stainless steel anodized, and does not even contain cork or plastic shims; it is reduced to a small 20x20 square. A straight face with very clean lines for the outside; chamfered edges on the inside to prevent the risk of being scratched if case of contact inside a shower cubicle. The claw of the clip is doubly chamfered to allow panels to be installed on edge without a notch, to ensure continuous pressure of the seal on the tray and absolute watertightness. This model can have an integral cam to simplify assembly of a panel - and is then notched - and pressurization of its waterproofing seals in some situations of Walk-in systems or enclosures with sliding doors.
Clip without notch ope.8 20x20 unit

chromed
50325B
BSS anodised 50326C

Clip without notch ope.10 20x20 unit

chromed
50365V
BSS anodised 50366W

Clip without notch ope.8 20x20 eccentric cam unit

chromed
50327D
BSS anodised 50328F

31. Capsi clips: range of square clips 40 x 40
The small model Capsi clips have the Capsi screw cover. Small (40x40 mm) and square, they fade to the maximum extent into the background of a Capsi shower enclosure. They tighten very efficiently despite the miniaturisation and enable panels to be fixed to threshold strip if there is a risk of these strips flipping over under the action of a door flag fixed to the vertical of the clip, or due to transmission of these forces by a stiffener. Supplied as standard with cork shims for glass of 6, 8 or 10 (12 mm possible on request), they can be fitted as an optional extra with very hard transparent plastic shims and a plain screw cover (without the Adler logo). In aluminium bronze, gloss chromed, brushed nickel and gilded, as standard.
Counterplate clip 40x40 - wall/gl unit

chromed
50300Z
brushed nickel 50301A
gilded 50302B

Counterplate clip gl/gl.90° unit

chromed
50309K
brushed nickel 50308J

Counterplate clip gl/gl.90° unit
chromed
50311M
brushed nickel 50314Q
gilded 50315R

2 transparent plastic clip shims and 1 cover
unit
chromed
50303C
brushed nickel 50304D
anodisé naturel 50305F
32. Capsi clips: design clips in stainless steel
The stainless steel version of the Capsi clip, refined and profiled, to harmonise with the design of the Adlock and Adslide partitions. Thickness: 6 to 12 mm.
Counterplate clip wall/gl unit

PSS 50312N
BSS 50313P

Clip with notch op.8 25x30 PC

Fixe
PSS
50370A
PSS 50369Z
Mobil
PSS
50374F
BSS 50375G

Treshold sections see family 780d
33. Adler and Venus clips: shower and handrail
34. Venus clips: clean design, always original
Clips with counterplate to form screens 6 to 10 mm in thickness. In the VENUS hinge product range. Supplied with 1mm thick cork shims.
Counterplate clip wall/gl unit

chromed
50401K
matt chromed 50420F
white 50427N
gilded 50424K
Counterplate clip gl/gl.90° unit

chromed
50428P
white 50436X
gilded 50435W

Counterplate clip gl/gl.135° unit

chromed 50441C
matt chromed 50442D
white 50444G
gilded 50443F
Counterplate clip gl/gl.180° unit

chromed
50437Y
matt chromed 50438Z
white 50440B
gilded 50439A
Counterplate clip - équerre wall/gl unit

chromed
50449M
matt chromed 50450N
white 50475Q
gilded 50474P
35. Adler Selection clips : shower and guard
36. Adler S clips for showers, partitions, counters
The smooth and very clean design of these square and very flat counterplate clips allows them to blend naturally with the Isodouche, Saloon and Super Saloon hinges and even to combine with the Adlock tube hinge and handle models in a self-supporting partition. The 5 options make it easy to produce a wide variety of panel structures and fixings in a shower and fixed glass connections in full and regular partitioning, display glazing, counters, sneeze guards with separators etc. For a thickness of 8 to 12 mm.
Counterplate clip 50x50 - wall/gl unit

chromed
50500S

Counterplate clip 50x50 - gl/gl - 3 starts unit

chromed
50508A
matt chromed 50509B

Counterplate clip 50x50 - gl/g.90° unit

chromed
50504W
matt chromed 50505X

Counterplate clip gl/gl.180° unit
chromed
50506Y
matt chromed 50507Z

Counterplate clip wall/gl unit

chromed
50502U
matt chromed 50503V

37. Door knobs, Stiffeners
This range of stainless steel tube connectors designed by Adler is the perfect partner for the Adlock handles (see 707) for façade or partition assemblies in coated glass from 6 to 15 mm. Very easy adaptation to a greater thickness on request. A number of very simple alignment adjustments facilitate installation. Standard finish brushed stainless steel, optional mirror polished finish on special order. Very clean and innovative design with smooth face.
Adjustable connector gl/gl unit

BSS
73268Q

Connector with spacer dist. 78.5 - gl/gl.90° unit

iBSS
73256B

Connector with spacer dist.76 -wall/gl unit

BSS
73242M

Connector dist.100 unit

BSS
73244P

Connector dist.78.5 - gl/gl.90° unit

BSS
73257C

Connector dist.76 -wall/gl unit

BSS 73240K

Connector dist.76&216 - wall/gl unit

BSS
73241L

Connector gl/gl.180° unit

BSS
73243N

Fixing point M8 flat suport unit


BSS

Ø 30 73258D
Ø 60 73278A

38. Adler and Capsi knobs for doors and gates
38.Adler and Capsi knobs for doors and gates
39. Capsi square knob 30
The Capsi knobs are matched with the hinges, clips and stiffeners that comprise this range, mainly for shower enclosures. 30 mm square with a groove to make them easy to hold between wet fingers. A few clever design ideas in these parts make them extremely easy to install despite their square shape. In aluminium bronze with standard finishes chromed, brushed nickel or gilded. Glass drill hole dia.12 mm.
Square knob 30 single
unit
chromed
69800V
brushed nickel 69801W
gilded 69802X

Square knob 30 double
unit
chromed
69810G
brushed nickel 69811H
gilded 69812J
Knob kit - Prestige transparent plastic
unit
chromed
69813K
brushed nickel 69814L


40. Adler knob dia.26
Adler push-pull knob, originally designed as a winder knob, ergonomic and discreet in shape and easy to grasp in the hand despite its small size. A discreet door knob solution to maintain the total transparency of Adler or Epsila shower enclosures. In brass with a chromed or brushed nickel finish. Glass drill hole dia.12 mm.
Knob dia.26 single
unit
chromed
69901F
satin polished 69906L

Knob dia.26 double
unit
chromed
69903H
matt chromed 69910Q
white 69907M
41. Adler knob dia.20
Adler push-pull knob, designed historically for drawers, display cabinets etc. Here supplied with screws and plastic seals for tightening onto a glass door as a single or double knob. In brass with a gloss chromed or brushed nickel finish. Glass drill hole dia.12 mm.
Knob dia.20 single
unit
chromed
69880H

Knob dia.20 double
unit
chromed
69881J


Knob dia.20 single - no screw
unit
chromed
69950J
red brass 69952L
blue brass 69954N
yellow brass 69955P
42. Adler knob dia.35
Knobs for doors and gates, diameter 35 mm, with 3 very useful seals for easy grasping in the hand. A great classic in the Adler catalogue. In brass, chromed, matt chromed and gilded. Glass drill hole dia.12 mm.
Knob dia.35 single bonded
unit
chromed
69965Z
matt chromed 69971G
gilded 69966A

Knob dia.35 single
unit
chromed
69967B
matt chromed 69973J
gilded 69968C
white 69972H
Knob dia.35 double
unit
chromed
69969D
matt chromed 69975L
white 69974K

43. Clip-on or screw-fixed stiffener, for enclosures, partitions
44. Adslide stiffener dia.25
The Adslide stiffeners are made of stainless steel tubing, diameter 21x25 (thickness 2). They are very strong and are designed to stiffen between fixed panels or between panel and wall, square or parallel. They can also be used as rails for Adslide suspended roller tracks and Adlock façade stiffeners (typically less than 2m50 in length): any combination of these functions is also possible. These stiffeners are fixed to the glass by washers dia.25 with screw covers. The construction of the stiffeners offers exceptional tearing strength; they are fully modular and can be adapted to any type of end fitting (adjustable caps, washers etc.) or screw-in points perpendicular to the axis of the stiffener at any point on its length. Standard finishes brushed stainless steel and polished stainless steel. Glass drill hole dia.14 mm for round façade fixing and dia.12mm for square façade fixing and expander.
Square expander - glass
unit
plain
69840P


Façade fixing - tube dia. 25
unit
PSS
73237G
BSS 73233B
Round expander - glass
unit
plain
69841Q


Expander- wall
unit
plain
69843S

Adjustable cap fixing dia.25
unit
PSS
69845U
BSS 69844T


Round expander fixing dia.25
unit
PSS
69847W
Square expander fixing 20x20
unit
PSS
69848X
BSS 69849Y


Round stiffener dia.25
kit 1.40m
PSS
69832F
BSS 69834H

Adjustable Round stiffener dia.25
kit 1.40m
PSS
69833G
BSS
69835J
45. Capsi stiffener, 20 square
The Capsi stiffeners are made of square stainless steel tubing 20x20 (thickness 1). They are very strong and are designed to stiffen between fixed panels or between panel and wall, always square: no caps available, unlike the Adslide stiffeners. These stiffeners are fixed to the glass with 20mm square washers with screw covers. The construction of these stiffeners provides exceptional tearing strength; they are fully modular and can be adapted to any type of end fitting (on wall or glass) or screw-in points perpendicular to the axis of the stiffener at any point on its length. Standard finishes brushed stainless steel and polished stainless steel. Glass drill hole dia.12 mm for façade fixing and expander.
Façade fixing tube 20x20   unit

PSS
69852X
BSS 69851W



Square stiffener 20x20
kit 1.40m
PSS
69836K
BSS 69837L
kit 1.40m
PSS 69863P
BSS 69864Q
46. Adler adjustable clip-on stiffener
The Adler stiffener with adjustable clip end fittings will stiffen any type of glass structure easily without predrilling the glass, with any angle between the panels to be stiffened or between panels and wall. A complete range of parts for invisible wall fixings or through a wall plate for weaker supports, with straight or angled start (45 degrees). Parts and tubes in brass, with a chromed, matt chromed or gilded finish
Wall baseplate - 45 deg
unit
chromed
69992D

Wall baseplate - 90 deg
unit
chromed
69989A
gilded 69991C
Adjustable end clip
unit
chromed
69980R
matt chromed 69981S
gilded 69982T

Wall plate
unit
chromed
69986X
matt chromed 69987Y
gilded 69988Z
Tube dia.22
LG 1m25
chromed
69983U
matt chromed 69984V
gilded 69985W

47. Door handles and locks
48. Adler Selection stainless steel handles various types
49. Square stainless steel handle
Handles in polished stainless steel (brushed stainless steel finish available on request), square section 20x20: half handles with inner finger button. The fixings are optimized for glass 8 mm in thickness. Drill hole diameter 10 mm. The horizontal model (500 mm c to c) can function well as a towel holder. The vertical model (baseplate 300 mm) is very discreet. Drill hole Ø 10 mm.
Horizontal handle single - 20x20
LG 520 mm
PSS
70519B

Vertical handle single - 20x20
LG 320 mm
PSS
70518A


50. Adlock stainless steel lever handles with or without lock51. Adlock round stainless steel handle
Range of single or double stainless steel lever handles Ø20 to 45 mm as standard for doors from 6 to 16 mm (very easily adaptable to doors of any thickness). These handles are available from stock (some standard sizes) or, more generally, are bespoke manufactured: length, c to c distances, additional spacers to be defined by the customer on an order form available to download on our website or obtainable from our technical sales. Short lead times. French manufacture. Standard finish “brushed stainless steel” grain 400. Optional “mirror polished” finish to be added to the order: code 70756K for single handles or 70757L for double handles. Can also be produced in other materials, shapes and finishes.
Finger-pass knob - dia 40
unit
brushed nickel
70766V

Round knob - dia 30
unit
brushed nickel
70765U

Double handle - dia 20
H 300
unit
brushed nickel
70767W

Double handle - dia 20
H < 950
unit
brushed nickel
70758M

Double handle - dia 25
H < 350
unit
brushed nickel
70705D

Double handle - dia 25
H < 950
unit
brushed nickel
70706F

Single handle - dia 25
H < 350
unit
brushed nickel
70700Y

Single handle - dia 20
H < 950
unit
brushed nickel
70759N

Single handle - dia 25
H < 950
unit
brushed nickel
70701Z

Washer dia.60 - untempered laminated glass - double spacer
J2
brushed nickel
70807Q

Finish option - polishing
x1
single handle
70756K
Double handle 70757L

Untempered laminated glass

laminated glass, tempered or not
52. Aluminium sections: wall, threshold, edge, seal 53. Aluminium sections for shower enclosures
For easy, reliable fixing on any type of shower enclosure wall or wall covering, with very low play and without joints or framing sections, Adler has developed a range of aluminium sections, chromed or anodized with a brushed stainless steel finish, each integrating multiple functions: anchorage and retention of sealing mastic on a wide variety of substrates; screw points for the fixings (clips) or hinging parts (hinges); grooves for durable fixing of any deflector, sealing/braking, waterproofing or anti-finger trap sections. These sections are for shimming, then bonding and finally screw fixing after back-drilling the wall and are a simple and effective method for correcting wall flatness and verticality defects. They also mean that clips can be fixed to the tray without drilling it. And the sections, called make-up models, can also compensate for +/-4 mm of play or defect and make some shower cubicle models reversible: ideal for the distribution and factory assembled sectors. The wall sections are designed to take Capsi hinges and clips and Clip-In Door and Adler VF lift-off hinges as standard
Threshold strip 14x5
78022Z/78023A : LG 1m
78024B/78025C : LG 1.70m
78026D/78027F : LG 2 .70m
chromed
78022Z
78024B
78026D
anodized stainless steel finish 78023A
78025C
78027F

Screw fix point
unit
plain
78028G

Flat section 38x5
c to c 1550
78004F : LG 2.14m
78005G : LG 2.80m
chromed 78004F
anodized stainless steel finish 78005G


Flat section 38x5
c to c 1800
78002C : LG 2.14m
78003D : LG 2.80m
chromed
78002C
anodized stainless steel finish 78003D

Flat section 25x5 *
78035P : LG 2.14m
78036Q : LG 2.80m
78034N : LG 2.80m
chromed
78035P
anodized stainless steel finish 78036Q
plain 78034N

Flat section 25x5 *
c to c 1550 & 1800
78014R : LG 2.14m
78015S : LG 2.80m
78013Q : LG 2.80m
chromed
78014R
anodized stainless steel finish 78015S
plain 78013Q
Flat section 25x5 *
c to c 1550 & 1800/ raidisseur
78020X : LG 2.14m
78021Y : LG 2.80m
78019W : LG 2.80m
chromed
78020X
anodized stainless steel finish 78021Y
plain 78019W

Flat section 25x5 *

78032L : LG 2.14m
78033M : LG 2.80m
78031K : LG 2.80m
polished
78032L
anodized stainless steel finish 78033M
plain 78031K
Make-up section - 25x5 *
c to c 1550 & 1800
78011N : LG 2.14m
78012P : LG 2.80m
78010M : LG 2.80m
polished
78011N
anodized stainless steel finish 78012P
plain 78010M

Make-up section - 25x5 *
c to c 1550 & 1800/ raidisseur

78017U : LG 2.14m
78018V : LG 2.80m
78016T : LG 2.80m
polished
78017U
anodized stainless steel finish 78018V
plain 78016T
* Delivered with 1 flexible seal for watertightness and 1 hard seal for Capsi usage.
54. Aluminium make-up section for door panels

The range of aluminium sections for shower cubicles is completed by more solid sections for heavy fixings and intensive use. They can also be used to remedy more serious defects of parallelism between walls or dimensional errors. They take standard half-plate wall hinges.

Make-up section - 28x42
c to c 1550
LG 2.80m
anodized stainless steel finish 78009L


Make-up section - 38x42
c to c 1800
LG 2.80m
anodized stainless steel finish 78007J

55. Aluminium edge section: protection and seal
Adler develops innovative systems for clip-on and sport fixing of uncoated laminated glass. To protect the fragile edges and form an initial barrier to moisture diffusion in the PVB insert, for example, Adler has designed a very fine adhesive aluminium section for bonding around 55.2 glass. This very fine section contains a groove in which to fit a specially developed seal profile which is used for indexing in the closed position and total waterproofing of a door on an Adlock pivot or Adler VF hinge. This section is also ideal for forming a seal on the free edge of a Clip-In Door without damaging the exceptional transparency of that product.
Edge section 10x2
adhesive seal
LG 2.20m
anodized stainless steel finish 78050A


double glass start section
glass 10 mm - ADLER VF
LG 2.45m
anodized stainless steel finish 78072A
polished 78073B

Single glass U section
glass 10 mm - ADLER VF
LG 2m45
anodized stainless steel finish
78069X
polished 78070Y

U section
glass 8mm
78052C/78053D : LG 2m
78062P : L 3.80m
78063Q : L 4m
polished 78052C
polished 78062P
anodized stainless steel finish 78053D
anodized stainless steel finish 78063Q

Threshold section with clip and seal - glass 8mm
78077G/78079J :
LG 2.40m
78078H/78080K :
LG 1.20m

polished 78077G
polished 78079J
anodized stainless steel finish 78078H
anodized stainless steel finish 78080K

Clips, see 503e
U-section fixing kit
unit 78061N
56. Miscellaneous flat aluminium sections
The wall flats 38 mm wide used to fix Capsi hinges to walls which are not flat or vertical can be usefully installed as threshold strips or plinths to start and support the construction of self-supporting structures. With these sections, a frame is made on the floor which is perfectly to size and level and absolutely horizontal and into which the various connectors supporting the partition can be screw fixed directly; the sections are therefore supplied finished but without machining; this can consist simply of milled holes to be drilled at the time of assembly to match the actual dimensions of the installation.
Flat section 38x5
78029H : LG 2m14
78030J : LG 2m80
chromed
anodized stainless steel finish

57. Seals and waterproofing profiles
58. Seals and waterproofing profiles
59. The waterproofing profiles for the Epsila range
The Epsila range of Capsi, Clip-In Door, Adler VF, Adslide and Adlock shower enclosures embodies the Adler research to achieve transparent solutions without seals or frames but watertight in use. The few linings that remain essential, between fixed panels and walls for example, can be obtained simply by pre-bonding silicone profiles on the matching edges of the fixed panels. The finish quality of the installation is impeccable; the installation time is significantly reduced. At the base of the door, Adler recommends bonding of deflector profiles which force the water back inside of the shower cubicle: never use seals, which obstruct the free movement of the door and its very precise closure.
Bonded square seal profile
8x8mm
LG 2.20m
transparent PMMA 79036K


Water drain deflector profile
self-adhesive 13x13mm
LG 1.95m
transparent polycarbonate 79043S

Adhesive tubular seal profile
10mm
RL 50m
tpe-p-s
79092V

Adhesive tubular seal profile
6mm
RL 10m
tpe-p-s
79090T
RL 50m
tpe-p-s 79091U
Adhesive tubular seal profile
8mm+
LG 1.20m
translucent silicone 79061M
RL 3.50m
translucent silicone 79062N
RL 25m
translucent silicone 79016N
60. Range of PVC clip-on seals and waterproofing profiles
A complete range of seals and waterproofing profiles fixed with a PVC clip. Some profiles are deflectors, some have a lip or bead acting as a seal and others integrate both functions in the same profile All are at least half hard: the clip is rigid when the lips have to remain flexible. Sometimes the clip contains internal stops and small, flexible PVC lips for adaptation to various glass thicknesses and good adhesion to the edge of the panel. The materials are constantly developing and the majority of Adler seals offer maximum resistance to UV radiation, for example, and to yellowing. Where appropriate, the lips of the seals are grained to limit the risk that they might stick together during prolonged closure; and the risk of premature damage to the seals – by tearing or pull-of. In the latest version of the magnetic seals, they are reversible (called multipolar), preventing any risk of confusion between North and South seals. These advantages of versatility and mechanical, UV and sticking resistance again slightly limit the transparency of the seal: it remains translucent.
Deflector profile
perpendicular lip - 6-8mm
LG 2m
translucent PVC


Water drain deflector profile
perpendicular lip - 6-8mm
LG 2m
translucent PVC

Central lip seal profile
6-8mm
LG 2.20m
translucent PVC


Central lip seal profile
8mm
LG 2.20m
translucent PVC


seal profile
water drain - 4-6mm
LG 1m
translucent PVC


seal profile
water drain - 6-8mm
LG 1m
translucent PVC

Offset lip seal profile
4-6mm
LG 1m
translucent PVC


Offset lip seal profile
6-8mm
LG 1m
translucent PVC

Offset lip seal profile
6-8mm
LG 2m
translucent PVC


Magnetic seal profile - North
90deg 6-8mm
LG 1.95m
white PVC

Magnetic seal profile - South
90deg 6-8mm
LG 1.95m
white PVC


Magnetic seal profile
multipolar 6-8mm
LG 2m
white PVC

Tubular seal profile
4-6mm
LG 1m
translucent PVC


Tubular seal profile
6-8mm
LG 2m
translucent PVC

61. Standard profile for an aluminium edge groove
Adler also offers a waterproofing profile model to slide into a standard groove in aluminium edge sections.
Tubular seal profile/aluminium section
10mm
LG 1m
grey PVC

62. Adler Kit seals and waterproofing profiles
63. The range of Adler seals in Adler Kit
Adler kit for waterproofing profiles, PVC clip-on or polycarbonate bonded: see in detail in 790a and 790b.
seal profile
water drain - 6-8mm
2 x 1m
translucent PVC


Tubular seal profile
6-8mm
LG 2m
translucent PVC

Offset lip seal profile
6-8mm
2 x 1m
translucent PVC


Deflector profile
autocollant - 13x13mm
LG 1.95m
transparent polycarbonate

Magnetic seal profiles -
North/South 90° - 6-8mm (180° applicataion: 2 seals with same polarity - eg. : N/N ou S/S)
2 x 1.95m
white PVC


Water drain deflector profile
perpendicular lip - 6-8mm
LG 2m
translucent PVC

Deflector profile
perpendicular lip - 6-8mm
LG 2m
translucent PVC


Offset lip seal profile
4-6mm
LG 1m
translucent PVC

Tubular seal profile
4-6mm
LG 1m
translucent PVC


seal profile
water drain - 4-6mm
LG 1m
translucent PVC

Magnetic seal profiles
multipolar 6-8mm
2 x 2m
white PVC


Offset lip seal profile
6-8mm
LG 2m
translucent PVC

64. Adler Kit: seal for aluminium edge
Adler kit for waterproofing profiles fixed in an aluminium section: see in detail in 790c.
Tubular seal profile/profil alu
10mm
LG 1m
grey PVC

65. Adler Kit: mitring cutter for seals
Adler kit offers a very precise and safe mitring cutter for easy trimming of waterproofing profiles. This cutter will prove an essential tool for repeated shower cubicle installations whenever it is necessary to adapt the length of the standard profiles to the actual dimensions of the installation
Mitring cutter /seals

unit
